SKID STEER 10K-14K



Model Axle Description Tire Size GAWR GVWR
SKID STEER 10K
12x81" SSBC 10K 2 - 5200# Dexter ST225/75R/15 LRD 5080# 9990#
14x81" SSBC 10K 1-Electric Brake Nev-R-Adjust
16x81" SSBC 10K E-Z Lube - 1/2 Cambered

SKID STEER 14K
12x81" SSBC 14K 2 - 7000# Dexter ST235/80R/16 LRE 7000# 14000#
14x81" SSBC 14K 2-Electric Brakes Nev-R-Adjust
16x81" SSBC 14K E-Z Lube - 1/2 Cambered
  • Coupler: 2 5/16" Forged Adjustable 5/Position
  • Jack: 7000# Drop Leg
  • Fenders: HD Diamond Plate Straight
  • Floor: 2" Treated Pine
  • Brake: Electric 2 Wheel on 10K. All Wheel on 14K.
  • Break Away Unit w/Charger
  • 4" Drop Axles
  • Suspension: Double Eye on 10K
  • Suspension: Slipper Spring on 14K
  • Stake Pockets
  • DOT Reflective Tape
  • Flush Mount LED Lights
  • 4 D-Rings
  • Spare Rack
  • Colors: Refer to Chart
  • Frame: 6x4x5/16
  • Front Bump Rail: 3" Square Tube
  • Crossmembers: 3" Formed Channel
  • Tongue: 6" Channel Wrap x 48"
  • 10000# Drop Leg Jack
  • Spare ST225/15 Radial LRD on 6-Hole
  • Spare ST235/80R/16 LRE on 8-Hole
  • 4' Slide-N-Ramps
  • 4' Fold Up Channel Ramps
  • 5' Fold Up Channel Ramps
  • Spring Assist on Fold Up Ramps
  • Weld-on D-Rings 5/8"
  • Other Options Available
