DUMP 70



Model Axle Description Tire Size GAWR GVWR
DUMP 70 (Tandem Axle)
5x10 DP 70 2 - 3500# Dexter ST225/75R/15 LRD 3500# 7000#
  1 - Electric Brake Nev-R-Adjust
  E-Z Lube - 1/2 Cambered

6.5x10 DP 70 2 - 3500# Dexter ST225/75R/15 LRD 3500# 7000#
  1 - Electric Brake Nev-R-Adjust
  E-Z Lube - 1/2 Cambered
  • Coupler: 2" Forged Adjustable 5/Position
  • Jack: 2000#
  • Fenders: HD Diamond Plate Straight
  • Floor: 10 GA Sheet Metal
  • Width: 60" Inside Box on 5x10. 77" on 6.5x10.
  • Brake: Electric 2 Wheel
  • Break Away Unit w/Charger
  • Primed & Painted Underside
  • Dual Swing Out Doors
  • Spare Rack
  • Sealed Flush Mount LED Lights
  • Wiring Harness
  • Lockable Battery/Pump Box
  • Deep Cycle 12V Marine Battery w/110V-5 Amp Charger
  • Color: Black
  • Frame: 5" Channel
  • Sides: 20" Formed
  • Tongue: 5" Channel Wrap
  • Dump Body Frame: 4" Channel
  • Crossmembers: 3" Channel 24" OC
  • Tarp Bracket & Tie Downs
  • Dump Components:
  • Hoist: Single Cylinder
  • Power Up/Power Down
  • Control: Pistol Grip w/10' Cord
  • Safety Prop
  • Caulked Seams on Dump Body
  • DP 70 Options
  • Electric Brake (2nd Axle)
  • Single Flip Up Door
  • Tailgate/Spreader Gate (Dual Hinge)
  • 5/8" D-Rings Inside Box (Priced Per D-Ring)
  • Scissor Lift
  • Tarp (Shipped Loose)
  • Dump Tarp Installation
  • Spare ST225/15 Radial LRC
